COMTRAK - AN-2000 - View larger

Online only

COMTRAK - AN-2000 - Micro headset for FTA-750/550/450/250 and on-board intercom systems

COM-AN-2000

New product

129,00 €


Product not deliverable for the moment.

More info

PROFESSIONAL HEADSET / MICROPHONE FOR AERONAUTICAL USE

  • Elegant , reliable design leaves the pilot's hands completely free
  • GEL silicone pavilions wired in parallel , optimally adjustable.
  • Without the necessity of the particular pressures completely eliminate the environmental noises.
  • The ambient noise canceling microphone is precisely adjustable to a flexible boom.
  • Separate plugs are provided for connecting the headset and microphone to the communication / intercom device compatible with YAESU FTA-750/550/450/250 devices and onboard intercom systems.
  • The shielded cable is 1.5 meters long
    Headphone General
    Type: Dynamic (F50) Operating Temperature: -20 to 70 ° C
    Frequency Response: 100Hz to 8 kHz Cordage: Straight cord from headset to molded
    Sensitivity: 95 +/- 5 dB SPL plug, 150CM
    (1 kHz, 1 mW input for earcup side) Intercom Connections Plug:
    full volume on ear simulator Earphone Plug: PJ-055 (.25 ″ F6.3 phone plug)
    Impedance: 150 ohms (300 ohms each; wired in parallel) Microphone Plug: PJ-068 (.206 ″ F5.2 phone plug)
    Rate Input: 100mW Weights: 530g
    Max. Input: 250mW Headset size range Height: 10 to 14 cm
    Microphone and Amplifier: Color: Gray
    Element Type: Noise-canceling electret / Gray
    Frequency Response: 100Hz to 5 kHz Boom: Spring tension boom
    Operating Voltage (supplied by aircraft): 8-32 Volts DC
    Matching Impedance: 150-1000 ohms
    Sensitivity: -33 +/- 4 dB
    (ref: 0dB SPL = 20.0uPa at 1 kHz with 10 Vdc 150 ohms
    AC load)
