OM POWER - OM-2000PLUS - Power Amplifier 1.8-29.7 MHZ + 50 MHZ
OM-2000PLUS
New product
By buying this product you can collect up to 42 loyalty points. Your cart will total 42 loyalty points that can be converted into a voucher of 42,00 €.
Pay it by wire
and save an additional 29,49 €
More info
General description of the OM2000+ HF and 50 MHz Amplifier
The OM Power model OM2000+ is designed for all shortwave amateur bands from 1.8 to 29.7 MHz (including WARC bands) + 50 MHz and all modes. It is equipped with a ceramic tetrode FU-728F.
Specification of OM2000+:
| Frequency coverage: | Amateur bands 1.8 – 29.7 MHz including WARC + 50 MHz |
| Power output: | 2000 W in SSB/CW on HF bands, 1500 W in CW/SSB on 50 MHz, 1200 W in RTTY and DIGI modes (800 W on 50 MHz) |
| Input power: | Usually 40 to 60 W for full output power (USA model), 20 to 30 W (World gain model) |
| Input impedance: | 50 Ohm, VSWR < 1.5 : 1 |
| Power Gain: | 15 dB (USA model), 17 - 18 dB (World gain model) |
| Output impedance: | 50 Ohm unbalanced |
| Maximum output SWR: | 3:1 |
| SWR protection: | Automatic switching to STBY when reflected power is 350W or higher |
| Intermodulation distortion: | -32 dB below nominal output |
| Suppression of harmonics: | < -50 dBc on HF, < -70dBc on 50 MHz |
| Tube: | 1x FU-728F ceramic tetrode |
| Cooling: | Centrifugal blower + axial blower (external) |
| Power supply: | Switchable 220,230,240 V – 50 Hz (230,240,250 V - 60 Hz for North America models) |
| Transformers: | 1 toroidal transformer 3 kVA |
| Current max.: | 20 Amps (recommended minimal IE 20 Amps Circuit breaker) |
| Protection circuits: | - VSWR too high |
| - Anode current too high | |
| - Anode voltage error | |
| - Screen current too high | |
| - Screen voltage error | |
| - Grid current too high | |
| - Grid voltage error | |
| - Heating voltage error | |
| - Mistuning of power amplifier | |
| - Temperature to high | |
| - Soft start for fuse protection | |
| - "switch–on blocking" at opened amplifier | |
| Indications: | - 4.3" color touch screen display |
| Features: | - High level of protections |
| - Memory for faults and warning, easy maintenance | |
| - Automatic set-up anode current (BIAS) – no need to adjust manually after changing the tube | |
| - Many operational parameters on display | |
| - Full QSK with silent vacuum relay | |
| - Easy transport due to detachable HV transformer | |
| Mechanical parameters: | 390mm x 195mm x 370mm (width x height x depth) |
| Weight: | 24 kg (53 lb) |
