Optibeam

Fabricants

Optibeam - OB7-2WARC - 7 Element, 2 Band - 17 / 12 Agrandir l'image

Exclusivité web !

Optibeam - OB7-2WARC - 7 Element, 2 Band - 17 / 12

OB7-2WARC

Nouveau produit

En achetant ce produit vous pouvez gagner jusqu'à 10 points de fidélité. Votre panier totalisera 10 points de fidélité pouvant être transformé(s) en un bon de réduction de 10,00 €.


1 019,00 €


Produit non livrable pour l'instant.

Payez le par virement bancaire
et économisez 7,13 €

En savoir plus

Bands   17 / 12
Gain (dBd) *   5,1 / 6,0
Gain (dBi) **   12,7 / 13,6
F/B (dB)   24 / 22
VSWR
18,07 - 18,13 - 18,17   1,4 - 1,1 - 1,2
24,89 - 24,94 - 24,99   1,3 - 1,1 - 1,2

Elements (number)   7
Active Elements je Band   3 / 4
Max. Elementlength (m)   8.5
Boomlength (m)   5.1
Turning Radius (m)   4.81
Feedlines (number)   1 Coax 50 Ohm
Weight (kg)   25
Windload at 130 km/h   413 N / 0,52 m² / 5,6 feet²

* = average gain over dipol in free-space / for comparison: 2 el monobander 4 dBd, 3 el 5-6 dBd
** = average gain at 20m above ground (= dBd + 2.15 dB isotropic + about 5 dB ground reflection)
