Optibeam - OB9-3WARC - 9 Element, 3 Band - 30 / 17 / 12 Agrandir l'image

Exclusivité web !

Optibeam - OB9-3WARC - 9 Element, 3 Band - 30 / 17 / 12

OB9-3WARC

Nouveau produit

En achetant ce produit vous pouvez gagner jusqu'à 24 points de fidélité. Votre panier totalisera 24 points de fidélité pouvant être transformé(s) en un bon de réduction de 24,00 €.


2 439,00 €


Produit non livrable pour l'instant.

Payez le par virement bancaire
et économisez 17,07 €

En savoir plus

Bands   30 / 17 / 12
Gain (dBd) *   3,8 / 5,5 / 6,2
Gain (dBi) **   11,2 / 13,1 / 13,9
F/B (dB)   16 / 28 / 27
VSWR
10,10 - 10,12 - 10,15   1,3 - 1,1 - 1,2
18,07 - 18,14 - 18,17   1,3 - 1,2 - 1,3
24,89 - 24,94 - 24,99   1,2 - 1,1 - 1,2

Elements (number)   9
Active Elements   2 / 3 / 4
Max. Elementlength (m)   9,18
Boomlength (m)   6,10
Turning Radius (m)   5,51
Feedlines (number)   1 Coax 50 Ohm
Weight (kg)   45
Windload at 130 km/h   1.014N / 1,25 m² / 13,7 feet²

* = average gain over dipol in free-space / for comparison: 2 el monobander 4 dBd, 3 el 5-6 dBd
** = average gain at 20m above ground (= dBd + 2.15 dB isotropic + about 5 dB ground reflection)
