Optibeam - OB9-5 - 9 Element, 5 Band - 20 / 17 / 15 / 12 /10 Agrandir l'image

Exclusivité web !

Optibeam - OB9-5 - 9 Element, 5 Band - 20 / 17 / 15 / 12 /10

OB9-5

Nouveau produit

En achetant ce produit vous pouvez gagner jusqu'à 14 points de fidélité. Votre panier totalisera 14 points de fidélité pouvant être transformé(s) en un bon de réduction de 14,00 €.


1 459,00 €


Produit non livrable pour l'instant.

Payez le par virement bancaire
et économisez 10,21 €

En savoir plus

Bands   20 / 17 / 15 / 12 / 10
Gain (dBd) *   4,3 / 4,5 / 4,7 / 4,5 / 4,5
Gain (dBi) **   11,7 / 12,0 / 12,3 / 12,3 / 12,3
F/B (dB)   18 / 20 / 25 / 25 / 25
VSWR
14,00 - 14,19 - 14,35   1,3 - 1,0 - 1,2
18,07 - 18,13 - 18,17   1,4 - 1,1 - 1,3
21,00 - 21,25 - 21,45   1,6 - 1,1 - 1,6
24,89 - 24,94 - 24,99   1,4 - 1,2 - 1,3
28,00 - 28,50 - 29,00   1,6 - 1,2 - 1,5

Elements (number)   9
Active Elements je Band   2 - 3
Max. Elementlength (m)   10.94
Boomlength (m)   5.1
Turning Radius (m)   6.03
Feedlines (number)   1 Coax 50 Ohm
Weight (kg)   30
Windload at 130 km/h   578 N / 0,72 m² / 7,8 feet²

* = average gain over dipol in free-space / for comparison: 2 el monobander 4 dBd, 3 el 5-6 dBd
** = average gain at 20m above ground (= dBd + 2.15 dB isotropic + about 5 dB ground reflection)
